Black-box testing – methods – rationale

Previous	Next
eBook content table

1. Background

Software testing may be done on a software application of which we don’t know the internal workings. To us, testers, the application is a black box with inputs and outputs and we can only base our testing on the functional description of the application, using the inputs to trigger a certain result, that we can verify against the functional description. This is called black box testing.

2. Problem

Black box testing involves a bunch of possible test types that can be used. Each test type can potentially lead to a seperate dynamic test process. Creating a process for each test type also will lead to continuous maintenance of each process, the need of seperate guidelines, checklists, etc.

3. Solution

However, all these processes are quite similar and therefore it is better to describe one process: ‘the black box testing process’ and include possible deviations from this process in the description of the testing technique itself. This way we maintain one test process in case the internal structure, design, and implementation details of the system being tested are not known to the tester. In black box testing, the software is treated as a “black box” where only the inputs and expected outputs are considered, without any knowledge of the internal workings or code.

The main characteristics of black box testing are as follows:

No Knowledge of Internal Structure: Testers performing black box testing have no access to or knowledge of the internal code, architecture, or implementation details of the system. They focus solely on the system’s external behaviour and functionality.
Test Based on Requirements and Specifications: Black box testing is typically based on the system requirements, functional specifications, and other relevant documentation. Testers design test cases and execute them to validate whether the system behaves as expected and meets the specified requirements.
Focus on Inputs and Outputs: Black box testing primarily examines the inputs provided to the system and the corresponding outputs produced by the system. Testers verify that the system processes the inputs correctly and produces the expected results, without knowing how the system achieves those results internally.
Testing Scenarios: Testers create test scenarios that cover various situations, including normal, boundary, and exceptional cases, to ensure comprehensive coverage of the system’s behaviour.
User Perspective: Black box testing is performed from an end user’s perspective, focusing on the system’s functionality and behaviour as perceived by the users.
Validation of Functional Requirements: Black box testing is particularly useful for validating functional requirements, such as user interactions, system responses, data handling, and overall system behaviour.
Testing Techniques: Various testing techniques can be applied in black box testing, including equivalence partitioning, boundary value analysis, decision table testing, state transition testing, and exploratory testing.

Overall, black box testing is an important testing technique that helps ensure the quality and functionality of a system by evaluating its external behavior without relying on internal implementation details.

4. Advantages

Independence from Internal Implementation: Testers do not require access to the internal code or knowledge of the system’s implementation details. This independence allows for unbiased testing and evaluation from an end-user’s perspective.
Focus on User Requirements: Black box testing is driven by system requirements and specifications. It ensures that the software meets the desired functionality as outlined in the requirements, making it effective for validating against user expectations.
Higher-Level Testing: Black box testing is a high-level testing technique that verifies the system’s overall behavior and functionality. It helps identify issues related to data flow, user interactions, system responses, and overall usability.
Greater Test Coverage: Testers can create test scenarios that cover a wide range of inputs, including typical, boundary, and exceptional cases. This helps achieve comprehensive test coverage and increases the likelihood of detecting defects.
Early Detection of Defects: Since black box testing can be conducted in the early stages of development based on the specified requirements, defects can be identified and fixed before they propagate further into the system.
Easier to Use and Understand: Black box testing does not require specialized technical knowledge, making it suitable for non-technical stakeholders and domain experts to participate in the testing process. It allows for clear communication and collaboration among team members.
Realistic End-User Perspective: Black box testing simulates how end-users interact with the system, making it more likely to catch issues that impact user experience and functionality.
Time-Efficient: Black box testing focuses on the external behavior of the system, allowing testers to concentrate on validating functionality without the need for detailed code analysis. This can result in time-saving during the testing process.
Regression Testing: Black box tests can be designed to validate the system’s behavior after changes or updates, making it valuable for regression testing to ensure that existing functionalities remain intact.
Security Testing: Black box testing is often used for security testing, where testers attempt to identify vulnerabilities and potential security risks without knowledge of the system’s internal design.
Single process: No need to describe a testing process for each testing technique.

5. Disadvantages

Limited Code Coverage: Black box testing only examines the system from an external perspective without considering the internal code structure. As a result, it may not achieve full code coverage, missing certain paths and logic within the code that could lead to defects.
Inefficient for Complex Systems: In complex systems with intricate interactions between different components, black box testing may not be sufficient to uncover all possible defects. The lack of insight into the internal design may make it difficult to identify subtle integration issues.
Dependency on Specifications: Black box testing heavily relies on the accuracy and completeness of the specifications and requirements provided. If the requirements are ambiguous or incorrect, the test cases derived from them may not be effective in revealing defects.
Redundant Test Cases: Due to the lack of visibility into the internal code, black box testers may unintentionally create test cases that cover functionalities already tested in other parts of the application. This redundancy can lead to inefficient use of testing resources.
Difficulty in Error Localization: When black box testing detects a defect, it may not provide enough information to pinpoint the exact location in the code where the issue originates. This can make it challenging for developers to identify and fix the problem.
Limited Input Validation: While black box testing can test a wide range of inputs, it may not thoroughly validate input combinations or edge cases that could lead to unexpected behavior or security vulnerabilities.
Time-Consuming: Black box testing often involves testing the entire system from the user’s perspective, which can be time-consuming, especially for large and complex applications.
Ineffective for Performance Testing: Black box testing may not be the best approach for performance testing or load testing, as it lacks insights into the system’s internal mechanisms, making it difficult to optimize performance bottlenecks.
Difficult to Test Exceptional Scenarios: Testing exceptional scenarios, error handling, and recovery mechanisms may be challenging in black box testing since the tester is not aware of the internal error-handling logic.

6. Conclusion

Black box testing is an important testing process that helps ensure the quality and functionality of a system by evaluating its external behaviour without relying on internal implementation details.
It’s important to note that the choice of black box testing techniques depends on the project’s specific requirements, the application’s complexity, and the testing process’s goals. Combining multiple techniques can provide more comprehensive test coverage and improve the effectiveness of black box testing.
The choice of testing approach should be based on the specific requirements of the project and the desired testing goals.

7. Objectives

Black-box testing is embedded in the organization’s test framework. It is the collection of a number of testing techniques that use knowledge of the functionality of a software product, to plan, describe, execute, and report black-box testing.
Black-box testing may occur anywhere in the software testing life cycle, in any test level, any test environment, anywhere in the infrastructure. It may use risk-based testing, or not.
A collective of influencers and especially the own organization may set constraints and additional objectives on black-box testing.
The Black-box testing process is the overall workflow to follow in case the internal workings of the software application are not known.
Black box testing always involves the use of 1 or more testing techniques
Definition of ready needs to be in place before beginning the black box testing process
Definition of done needs to be defined before beginning the block box testing process
In normal circumstances, Black box testing must adhere to the risk-based testing approach.
Deviating from the risk-based testing approach must be well documented and approved by the appropriate channels

8. Notes

8.1 Black box testing techniques

Equivalence Partitioning: This technique divides the input domain into classes of data that should be treated similarly by the system. Test cases are then designed to represent each class, reducing the number of test cases needed while ensuring good coverage.
Boundary Value Analysis: Test cases are designed around the boundaries of the input domain, including both the minimum and maximum values. These boundary values are more likely to reveal defects related to data handling at the edges of the valid range.
Decision Table Testing: Decision tables are used to capture complex business rules with multiple conditions and possible combinations of inputs. Test cases are created based on the different scenarios defined in the decision table.
State Transition Testing: Suitable for systems with different states and transitions, this technique focuses on testing the system’s behavior as it moves between states based on inputs and events.
Use Case Testing: Test cases are designed based on the various use cases defined for the system. Each use case represents a specific interaction between the user and the system.
Error Guessing: Testers use their experience and intuition to guess potential error-prone areas in the application and create test cases to target those areas.
Ad Hoc Testing: Testers perform exploratory testing without following any predefined test plan, trying to identify defects based on their knowledge of the system and user behavior.
User Interface (UI) Testing: Focuses on validating the user interface’s correctness, layout, navigation, and usability.
Security Testing: This technique involves assessing the application’s vulnerability to security breaches and ensuring that sensitive data is adequately protected.
Compatibility Testing: This technique verifies that the application functions correctly across different platforms, devices, browsers, and operating systems.
Stress Testing: The application is subjected to high loads or resource constraints to assess its stability and performance under stress.
Usability Testing: This technique evaluates how user-friendly and intuitive the application is for end-users.
Regression Testing: After making changes to the system, regression testing ensures that the new changes do not introduce new defects and that existing functionalities continue to work as expected.

8.2 Contextual considerations

Software testing framework: The organization needs to identify the influencing factor (own organization, regulation, clients, etc.) and quality needs (e.g. reliability, functionality, etc.) to establish black-box testing. Black-box testing needs to be included in the organizational test processes (policy, strategy, stakeholders, vision, goals, objectives, roles and responsibilities, etc.), the test management processes (estimate, plan, monitoring, reporting, closing), and needs to be defined as a test-sub process (dependencies, process, deliverables, criteria, level of automation, etc.).
Black-box testing techniques: The organization needs to decide on the black-box testing techniques that will be considered. Each testing technique may lead to a test sub-process detailing/altering the black-box testing sub-process.
Life cycle: The organization needs to decide which black-box testing techniques will be used in which phases of the testing life cycle.
Test levels: The organization must decide which black-box testing techniques will be executed in which test levels.
Test environments: The organization needs to decide which black-box testing techniques will be executed in which test environments.
Infrastructure: The organization needs to decide whether black-box testing techniques are limited to the software product or also include infrastructure.
Risk-based testing: The organization needs to decide whether and how risk-based testing affects black-box testing.

8.3 Conceptual considerations

8.3.1 Black box testing process

A possible black box testing process typically involves several steps to ensure comprehensive software application testing from an end-user perspective. Below is a general outline of a black box testing process:

Requirement Analysis: Understand the project requirements, scope, and objectives. Review the functional specifications and other relevant documentation to gain insights into the system’s expected behaviour.
Test Planning: Develop a test plan that outlines the testing objectives, testing scope, entry and exit criteria, test environment requirements, and the resources needed for testing.
Test Case Design: Based on the requirements and functional specifications, design test cases that cover different functionalities and scenarios. Using techniques like equivalence partitioning, boundary value analysis, and decision table testing, derive test cases.
Test Data Preparation: Gather or create the necessary test data to execute the designed test cases. Ensure the test data covers various scenarios and includes valid, invalid, and boundary values.
Test Environment Setup: Set up the testing environment, including hardware, software, and configurations, to replicate the end user’s environment as closely as possible.
Test Execution: Execute the designed test cases in the test environment. Input the test data and observe the system’s behaviour and responses.
Defect Reporting: When a test case identifies a defect or unexpected behaviour, document the issue with detailed steps to reproduce it. Include relevant logs, screenshots, or additional information to help developers understand and fix the problem.
Defect Verification and Retesting: After developers fix reported defects, verify the fixes by retesting the affected functionalities to ensure the issues have been resolved. Also, perform regression testing to ensure that fixing one part of the code did not introduce new defects in other areas.
Test Coverage Analysis: Continuously track and analyze test coverage to ensure the testing process effectively covers the required functionalities and scenarios.
Exit Criteria and Test Closure: Evaluate the test results against the predefined exit criteria to determine whether the testing process is complete. Conduct a test closure meeting to review the testing process, its results, and any lessons learned.
Test Automation (Optional): Consider automating the selected test cases to improve testing efficiency, especially for repetitive or time-consuming scenarios.
Continuous Integration and Continuous Testing (Optional): Integrate black box testing into the continuous integration and continuous testing process to get fast feedback on code changes.
Performance Testing (Optional): If performance requirements exist, conduct performance testing separately to evaluate system performance under different load conditions.

The black box testing process is iterative, and the steps are tailored to the specific needs of the project. The process ensures that the software is tested thoroughly from an end-user’s perspective, validating that it meets the specified requirements and behaves as expected.

8.3.2 ATDD – Acceptance test driven development

ATDD stands for Acceptance Test-Driven Development. It is an Agile software development practice that emphasizes the collaboration between developers, testers, and business stakeholders to define and validate the acceptance criteria for user stories before implementing them. ATDD is closely related to Behavior-Driven Development (BDD) and Test-Driven Development (TDD).

The key principles and steps involved in ATDD are as follows:

Collaboration: ATDD encourages close collaboration among product owners, business analysts, developers, and testers. Together, they discuss and clarify the requirements, user stories, and acceptance criteria.
Acceptance Criteria Definition: During the planning phase of a sprint or iteration, the team collaboratively defines the acceptance criteria for each user story. Acceptance criteria are the conditions that must be met for a user story to be considered complete and accepted by the stakeholders.
Test Case Creation: Once the acceptance criteria are defined, the team works together to create acceptance tests (also known as acceptance criteria tests or customer tests) based on these criteria. These tests are written in a business-readable language and serve as a shared understanding of the desired behavior of the system.
Test Automation: The acceptance tests created during ATDD are often automated to serve as living documentation and to be executed as part of the continuous integration process. Automation ensures that the acceptance tests can be quickly and reliably executed for rapid feedback.
Implementation: Developers use the automated acceptance tests as a guide while implementing the user story. The goal is to ensure that the software satisfies the acceptance criteria and meets the intended business functionality.
Verification and Validation: Once the implementation is complete, the acceptance tests are executed to verify that the system behaves as expected and meets the predefined acceptance criteria.
Feedback Loop: If any acceptance tests fail during the verification process, developers and testers collaborate to identify and fix the issues. The feedback loop is an essential part of the ATDD process to ensure continuous improvement.

The main benefits of ATDD include improved collaboration, a shared understanding of requirements, quicker feedback on implemented functionality, and higher-quality software that aligns with business needs.
